An LTM has the 3 virtual servers, 2 SNATs, four self IP addresses defined, and the networks shown in the exhibit. Selected options for each object are shown below. Settings not shown are at their defaults.
Assume port exhaustion has not been reached. Vi rtualServerl Destination: 10.10.2.102:80 netmask 255.255.255.255 Pool: Pool with 3 members in the 172.16/16 network SNAT Automap configured Vi rtualServer2 Destination: 10.10.2.102:* netmask 255.255.255.255 Pool: Pool with 3 members in the 192.168/16 network Vi rtualServer3 Destination: 10.10.2.0:80 netmask 255.255.255.0 Type: IP Forwarding SNAT1 Source IP: 10.10.0.0 netmask 255.255.0.0 SNAT Address: SNAT Pool with 2 members
172.16.20.50 and 192.168.10.50 SNAT2 Source IP: All Addresses SNATAddress:
10.10.2.102 Floating Self IPs 192.168.1.1; 172.16.1.1; 10.10.2.1; 10.10.1.1

• A. Source IP: 10.10.2.1; Destination IP: 10.10.2.10
• B. Source IP: Either 172.16.20.50 or 192.168.10.50; Destination IP: 10.10.2.10
• C. Source IP: 10.10.2.102; Destination IP 10.10.2.10
• D. The request will be droped.
• E. connection attempt is made with a source IP and port of 10.10.100.50:2222 and a destination IP and port of 10.10.2.10:80. When the request is processed, what will be the source and destination IP addresses?

• F. Source IP: 10.10.2.1; Destination IP: pool in the 172.16/16 network C

A BIG-IP has the following objects configured: A SNAT pool with 2 members: 150.10.33.33 and 10.10.1.33 A load-balancing pool with 5 members: 10.10.1.1-10.10.1.5:80
The BIG-IP has two self-IP addresses: 150.10.10.10 and 10.10.1.10 A virtual server at 150.10.30.30:80 that is associated with both the SNAT pool and the load-balancing pool. If a client at IP address 200.10.10.10 initiates a connection to the virtual server, what will the source IP address be in the packets sent to the chosen pool member?

• A. 10.10.1.33
• B. 150.10.30.30
• C. 200.10.10.10
• D. 10.10.1.10
• E. It could be any of the addresses of the members of the load-balancing pool.
• F. 150.10.33.33

A monitor has been defined with an alias port of 443. All other options are left at their defaults. The administrator
wishes to assign it to a pool of members where the members' ports vary. Which is the result?

• A. For each member. If it is running an SSL service at the member port, the monitor may work. Otherwise, the monitor will fail and the member for each member, if it is running an SSL service at the member port, the monitor may work. Otherwise, the monitor will fail and the member will be marked down.
• B. For each member, if the member port is not 443, the member will be marked down. For each member,if the member? Port is not 443, the member will be marked down.
• C. For each member, the monitor will test member node at port 443. For each member, the monitor will test the member ? node at port 443.
• D. This assignment is not allowed since the port do not match.

After editing and saving changes to the configuration file containing virtual servers,
what is the immediate result?

• A. The new configuration is verified not loaded.
• B. The new configuration is neither verified nor loaded.
• C. The new configuration is verified and loaded.
• D. The new configuration is loaded but not verified.
• E. The new configuration is verified
• F. The new configuration is verified and loaded if is it syntactically correct.
